Fixture Integrated DALI-2 PIR + Light Sensor SR-DA9032A-PIR

The SR-DA9032A-PIR is a DALI-2 multi-sensor that is built directly into the luminaire through a 1/2 inch knockout. It combines a PIR motion sensor and a light sensor.

It is DALI-2 and D4i certified and powered by the DALI bus, so no extra power supply is needed.

Together with a DALI controller or D4i driver, lights switch and dim automatically with presence and daylight. This saves energy and helps meet building energy codes.

Key Features

• DALI-2 and D4i certified
• PIR motion detection, instance type 3 (303)
• Light level measurement, instance type 4 (304)
• DALI bus powered, max. 6mA
• Detection area up to 16 ft (5 m) at 8 ft (2.5 m) mounting height
• Mounts in the luminaire through a 1/2 inch knockout

Typical Applications

Luminaire makers and installers who want a sensor inside each fixture, for offices, classrooms, corridors and low bay areas.

Specifications

Part No.: SR-DA9032A-PIR
Power Supply: DALI bus
Max. DALI Current Draw: 6mA
Sensor Type: PIR motion sensor and light sensor
Detection Range: 16 ft (5 m) @ 8 ft (2.5 m) mounting height
Mounting: 1/2 inch knockout, fixture integrated
