KNX Smart Touch Panel V50s

KNX Smart Touch Panel V50s

The KNX Smart Touch Panel V50s is a versatile 5-inch smart home control panel designed to provide centralized and intuitive control of a wide range of KNX functions. Featuring a high-resolution 480 × 854 IPS touchscreen and a sleek aluminum faceplate, it combines modern aesthetics with powerful automation capabilities.

The panel supports up to 15 customizable control pages, covering essential functions such as switching, dimming, shutter control, scene management, value sending, RGB/RGBW/RGBCW lighting, color temperature control, HVAC, air conditioning, floor heating, ventilation, audio control, energy metering, and air quality monitoring.

Built-in temperature and proximity sensors enable intelligent environmental monitoring and more responsive automation. The V50s also supports up to 16 timing functions, 8 group events, 8 logic functions, and HCL (Human Centric Lighting) for advanced smart-building applications.

For personalization, users can customize interface icons via an SD card. The display orientation can be adjusted for vertical or horizontal installation, while its flexible wall-mounting design is compatible with 86 × 86 mm, German 60 mm, Swiss, Australian, and US standard wall boxes.

With its combination of elegant design, extensive KNX functionality, flexible installation, and intelligent automation features, the KNX Smart Touch Panel V50s is an ideal solution for modern residential, hospitality, and commercial environments.
