Description
O-range ECON® 3 one-gang junction box
- Article no: 9253-22
- EAN: 4013456550902
- Air-tight design with sealing membranes
- Toolless cable and conduit entries
- Integrated cable retention of the NYM cable, self-locking of the conduit
- Standardized separation of individual installation openings using a bridge
- It can be combined with all O-range® program applications
For panel thickness 7 – 40 mm
Depth 48 mm
Cut hole Ø 3 x 68 mm
Device screws +/- 6
Centre distance 71 mm
Conduit entries Ø 20 mm
6 Cable entries 3 x 2.5 mm² or 5 x 1.5 mm²
2 Cable entries 3 x 1.5 mm²
