N528C01 UNIVERSAL DIMMER 2-FOLD

Description

N 528C01 UNIVERSAL DIMMER 2-FOLD , AC 120 V, 2x 150VA

• Power supply: via KNX Bus line, 20VDC
• Rated voltage: 120V AC +10%/-15%, 50/60 Hz
• Rated current:
  • 2-channel: 2×1.3A@cosФ=1.0
  • 1-channel: 1×2.2A@cosФ=1.0
• N-system DIN-rail mounted device, width:4MU(1MU=18mm)
• Load output:


  Lamp type	2 channels	1 channel
  Incandescent lamps	150 W	250 W
  Low voltage halogen lamps with magnetic transformers	120 VA	200 VA
  Dimmable LED	<= 50 VA	<=50 VA

Two outputs for switching and dimming resistive, inductive or capacitive loads Automatic adjustment to leading edge or trailing edge control, depending on the type of load Rated operational voltage AC 120 V Rated frequency 50 / 60 Hz Rated power at +35°C ambient temperature: 150 VA per output or 250 VA for single output usage, without any minimal load per output Electronic protection of each output against overload, short circuit and temperature rise Screw terminals for connection and through-wiring of untreated single-core, stranded or multi-core conductors, 0.5 … 2.5 mm², AWG 20-13 Bicolor LED for indicating the switch status (red = on, green = off) or an error (orange, blinking) per output Bus-powered electronics Integrated bus coupling unit Bus connection via bus terminal block As a device for DIN-rail mounting on a TH35 mounting rail according to DIN EN 60715
