Theben iON 104 KNX

SKU: N/A Tags: a temperature sensor, application sensors, best temperature sensor, box push button, button and led, button push, button push button, button push switch, button switch, button to switch, cheap temperature sensor, control sensor, control temperature sensor, electric push button, electric push button switch, electric sensor, electric temperature sensor, electronic buttons, electronic sensors, external temperature sensor, hvac temperature sensor, i push buttons, knx, led button, led push button, led push button switch, led push switch, led pushbuttons, micro switch push button, price of sensor, price sensor, push button, push button as toggle switch, push button box, push button electric, push button electric switch, push button on switch, push button push button, push button start button, push button starter, push button starter button, push button starter switch, push button starters, push button switch, push button switch micro, push button switch symbol, push button to toggle switch, push button toggle switch, push in button, push on button switch, push on the button, push switch, push to switch, pushable button, pushbutton switch cover, pushbutton symbol, sensor house, siemens push button, starter buttons, starter switch button, switch and push button, switch temperature, switch to button, switch with button, symbol for push button switch, symbol for temperature sensor, symbol for temperature switch, symbol of push button switch, symbol push button, symbol temperature sensor, temp sensing, temp sensor hvac, temp sensor usb, temp switch sensor, temp switches, temperature control switch, temperature detector, temperature detector price, temperature detector sensor, temperature devices, temperature sensor, temperature sensor control, temperature sensor price, temperature sensor sensor, temperature sensor switch, temperature switch, Theben, thermostat probe, thermostatic sensor, usb temperature sensor

Description
Reviews (0)

Description

Push-button sensor with 4 buttons and 4 status LEDs with integrated temperature sensor
- Push-button sensor with 4 buttons and 4 status LEDs with integrated temperature sensor
- Secure communication with support of „KNX Data Secure“
- For controling of the functions switching, dimming, blinds, value transmitter, operating mode, scene, color control, sequence
- Up to 3 different telegrams per button
- Sending different telegrams with a short, long or double click
- Multi-colored status LEDs with adjustable colors for each LED separately
- Behavior of each status LED can be set: static, flashing or pulsing
- Brightness of each status LED can be individually adjusted via object or parameter
- Automatic brightness control of the status LEDs depending on the ambient brightness
- Integrated temperature sensor for visualization and temperature control via heating actuators
- Function monitoring via object (signaling dismantling)
- Installation of two iON push button sensors on standard double socket with accessory possible
- Transparent cover for individual labeling in the scope of delivery

Technical data

Operating voltage KNX	Bus voltage, ≤12.5 mA
Type of connection	KNX bus terminal
Colour	White (similar RAL 9016)
Ambient temperature	-5°C … 45°C
Type of protection	IP 20
Protection class	III
